| 加工定制：否 | 品牌：AST | 型号：AST2000 |
| 种类：压力 | 制作工艺：集成 | 输出信号：模拟型 |
Industrial OEM ASIC Designed Pressure Sensor
The AST2000 is anASIC-compensated, high quality, stainless steel media ***latedpressure sensordesigned for use in the measurement of liquids and gases. Intended for high volume applications requiring excellent performance, the AST2000 succeeds by offering highly competitive pricing. Complete with a fully welded stainless steel housing, high shock and vibration and EMI/RFI protection, the AST2000 will survive in the most extreme conditions.
-Krystal Bond Technology ™ - CE EN61326 - No Oil Fill, Welds, or Internal O-rings - Wide Operating Temperature Range - Wide Range of Media Compatibility - Rugged, Compact Design
- Industrial OEM Equipment -Hydraulic Systems -HVAC Equipment -Refrigeration Equipment -Automotive -Hydrogen Fuel Cells* -Energy / Water Management - Test Stands - Off-road / Construction Equipment *Consult Factory for media compatibility Click Here For Wiring Information
1Accuracy includes: Non-linearity, Hysteresis and Non-repeatability
AST2000 | A | 00500 | P | 1 | E | 0 | 000 |
Typical ranges. All ranges between 0-25 PSI and 0-10,000 PSI available. **Compound ranges up to -14.7 to 500 PSI available. Please consult factory. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Series Type | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Process Connection A= 1/4" NPT Male B= 1/8" NPT Male C= 1/4" BSP Male F = 7/16鈥�-20 Male UNF [SAE4] K = 7/16鈥�-20 Female UNF [SAE4] | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pressure Range Insert 5-digit pressure range code | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pressure Unit B= BAR K= kg/cm2 P= PSI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Outputs 1= 0.5-4.5V ratiometric 3= 1-5V 6= 1-6V | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Wetted Material 0= 17-4PH 1= 316L | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Options 000= No Special Options | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
